Quick Start Guide

QUICK GUIDE MANUAL
Rear Panel
1 2 3 4
5 84
6 7 9
ON : Powers On/Off
DC-IN: Connects the detachable D/C power adapter.
LNB-IN : One satellite cable can be connected
Audio output : Connects to TV using RCA cable
Video output : Connects to TV using RCA cable
COAXIAL : Connects to a digital audio system using S/PDIF cable
HDMI : Connects to TV using a HDMI cable for both audio and video signals
Ethernet : Connects the set top box to network
USB : Connects the USB memory stick or external HDD
