4.2.2 ActiveSync File Synchronization

ActiveSync files synchronization requires an ActiveSync partnership between the PDT and

the Host PC. Refer to “Setting up a Partnership”, above:

ü Select the files in the synchronization configuration for the PDT partnership.

ü Select Tools > Options from the ActiveSync command bar to configure the

synchronization options.

ü Place the file to be synchronized in the Synchronization folder created you’re My

Documents directory. Defaults to the desktop. During the ActiveSync connection, all

files in the Synchronization folder will be synchronized to the \My Documents

directory on the PDT.

Figure 4-2 Connected

4.3 Networking

Please see the 3.2.14 Owner, Table 3-33 Owner on page 3-45 for setting up the network

ID. And see the 2.5.6 Setting Up Wireless LAN RF to setup the 802.11b Wireless LAN for

RF connecting.
