Datasheet

35
* Note: All specications are subject to change without notice.
Features
Specications
Eco-Friendly
Anti-Bacteria
♦ Intel® Core™ 2 Duo ULV Processor
♦ 17” SXGA 380 nits LCD
♦ 5-wire Resistive Touch Screen(optional)
♦ 802.11a/b/g/n Wireless LAN(optional)
♦ +9V to +30V Wide Range DC input
♦ CE/FCC Class B, EN/UL60601-1 Medical Certication
Main Specications
Processor
Intel® Core™ 2 Duo U7500 1.06 GHz
Intel® Celeron M 440 1.86GHz
System Memory Supports DDR2 SODIMM up to 2GB
Chipset Intel® 945 GME + ICH7M
OS Support Windows® XP, Windows® 7, Linux
Expansion Interface Mini PCI x 1
Storage Disk Drive 2.5” SATA Hard Disk Drive/SSD x 1
Wireless
Communication
802.11a/b/g/n(optional)
Speaker 2W x 2
Power Requirement DC 9~30V
Display
Size 17”
Resolution 1280 x 1024
Max. Colors 16.7M
Luminance 380 nits
View Angle 170˚(H)/170˚(V)
Contrast Ratio 1000:1
Back Light Life Time 50,000 Hours
Touch Screen 5-wire Resistive / 35 million activities(optional)
I/O
USB
USB 2.0 x 6 ( for A2/A3 model)
USB 2.0 x 4 ( for A1/A4 model)
Serial Port
RS-232 x 1 (for A2/A3)
RS-232 x 1, RS232/422/485 x 1 (for A1/A4)
Ethernet Gigabit LAN x 1
Keyboard & Mouse PS/2 Keyboard/Mouse x 1
Video Out VGA x 1
Audio Mic-in, Line-out
Mechanical and Environmental
Power Consumption Full loading:55 Watts for A1/A2, 61 Watts for A3/A4
Operating
Temperature
0°C ~ 40°C(32°F ~ 104°F)
Storage
Temperature
-20°C ~ 60°C(-4°F ~ 140°F)
Mounting VESA 75/100 mm
Net Weight 12.3 lb (5.6 kg)
Certification CE/FCC Class B, UL 60601-1, EN 60601-1
2 x USB
2 x USB
PS/2 Keyboard/Mouse
Mic inCOM
Line out
VGA
LAN
COM
Power
LCD Brightness Control
Power On/ Off
Speaker Volume Control
17” C2D Slim Medical Panel PC
Fanless Slim Panel HIT Solution
ONYX-1722
