Installation Instructions

Thermo One
™
Refrigeration Sensor
INSTRUCTIONS
1. Remove the battery cap screw
from the bottom of the sensor
enclosure.
2. Install both AA lithium batteries into the
battery enclosure, noting proper polarity.
3. Install and secure the battery cap screw.
The sensor will begin transmitting at 4 second
intervals in order to facilitate gateway setup
and positioning.
4. Determine the mounting location by considering:
a. Location of cooler venting and airflow.
Note: Do not install in corner of cooler.
b. Minimize obstructions to gateway.
c. Vertical orientation of the sensor
provides best signal strength.
d. Locate at least 1 inch from
metal surfaces if possible.
5. Use included clip and mount into racking with zip
ties or mount to side of cooler with VHB tape.
Note: To remove clip slide toward base of sensor.
INSTALLATION TROUBLESHOOTING
It is imperative that the sensors can communicate
with a OneEvent™ gateway. The number of walls,
ceilings and metal objects in the signal path reduces
the strength of the radio frequency (RF) signals
between the sensor and the gateway. Accordingly,
some sensors may have diculties communicating to
the assigned OneEvent gateway. It may be necessary
to move the gateway closer to the sensor if
notifications are not being received during installation
testing.
Installation testing begins after installing the
batteries and ends by confirming the sensor reading
on the OneEvent app. The test mode transmits a
signal every 4 seconds for 60 minutes, after which
the Thermo One™ Refrigeration sensor reverts to the
default transmit cycle of 3 minutes.
LIMITATIONS OF OET RF SIGNALS
OneEvent™ radio communication systems are
reliable and are tested to high standards. However,
due to their low transmitting power and limited range
(as required by regulatory bodies) there are some
limitations to be considered:
· Receivers may be blocked by radio signals occurring
on or near their operating frequencies (i.e. signals
from garage door openers).
· Changes in the surrounding environment
(renovations or furniture that has been moved), can
disrupt radio communications between the sensor
and gateway.
Package Contents:
Thermo One Sensor (x1)
Mounting Clip (x1)
L91 AA Lithium Batteries (x2)
Installation Instructions (x1)
3M
™
VHB mounting tape (x1)
Changes and modifications to this device not ap-
proved by OneEvent
®
Technologies could void the
user’s authority to operate the equipment. If your
sensor fails to work after you have read the previous
sections, please contact your Dealer or OneEvent.
If you receive a “Low Battery” alert, immediately
replace them with (2) AA lithium batteries. Use of any
other type will eect sensor function.
TECHNICAL SPECIFICATION
Operating frequency: 433 MHz
Range: 100m in free air (min)
Protocol: OneEvent™ RF Link
Transmit interval: 3 minutes ± 15 seconds
Sensor message duration: 20ms
OET-100413 weight: 77 grams, including batteries
6
. Ensure the gateway is operating and
connected to the OneEvent server.
7. Allow a short time to elapse for the sensor to
connect to the gateway, then verify the sensor is
reading in the OneEvent app.
8. Once installed, no user interaction is required.
CONTACT US
Customer Service
OneEvent
®
Technologies, Inc.
505 Springdale St.
Mount Horeb, WI 53572
Phone: [phone]
Email: [e-mail]
Web: oneeventtech.com/support
FCC COMPLIANCE STATEMENT
is device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation. Note: the grantee is not responsible for any changes
or modications not expressly approved by the party responsible for compliance.
Such modications could void the user’s authority to operate the equipment.
FCC ID: 2AHZG-THERMONEW433
is device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux
appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions
suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de
l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d’en compromettre le fonctionnement.
