4.2.3 Connection Descriptions
Connector
Application
GPS Antenna
SMA female connector for optional GPS antenna.
RF Out
50Ω N-Type female connector for RF input from
antenna
DC Input
DC power input 10 to 36 volts.
Warning: Ensure Correct Polarity
Ground Post
Connection to building ground
Fuse
30 amp Fuse
ATCS Ports
2 x DB25 female connectors for ATCS data
Ethernet
2 x RJ45 connector for Ethernet 10/100 Base-T
interface
Console / Serial
RJ45 8-pin connector wired using the Cisco
interface specification for serial access and console
access via an adapter cable
Reset Button
Recessed access to system reset function
Push Buttons
Select and Enter functions for user interface
