Installation Guide

Page 5 of 10 April 2021
4 Physical Installation
4.1 Introduction
A Airlink WCP radio is comprised of software and hardware which is packaged in an indoor enclosure
intended for mounting in a 19” rack or directly attached to a wall board.
4.2 Airlink WCP Enclosure
4.2.1 Specifications
Enclosure Material
Aluminum Alloy
Dimensions (W x D x H)
9” x 9” x 9”
(230mm x 230mm x 255mm)
Operating Temperature
-40° F to 158° F
(-40° C to 70° C)
DC Input Power Range
10 to 36 VDC
Power Consumption
No load : 100 watts @ 24 VDC
Peak load : 150 watts @ 24 VDC
