[ SYSTEM MENU ]
Quit
Transmit Mode
Maintenance Mode
[ MAINTENANCE MENU ]
Quit
PT Setting Status
I/OCheck
Display History
Memory I ni t.
Memory Swi tches
Comm. Met hod
Key Press Sound
Buzzer Sound
RS-232C
OFF
Putting-Out Time
Resume Function
OFF
None
ON
[ MEMORY SWITCH MENU (1/2) ]
Support Tool Mode NT600S
EXIT
SAVE
EXIT
NEXT
PAGE

Section 3-6
4-6-4 Setting the RS-232C Communication Conditions
When connecting the NT600S to the host by the RS-232C method, set the follow-
ing communication conditions.
Item Settin
g
Factory-Settin
g
RS-232C Speed
2400/4800/9600/19200bps
(to be set to the same value as set for the Host)
2400bps
Data bit len
g
th 7 bits/8 bits 8bits
Stop bit len
g
th 1 bit/2 bits 1bit
Parity bit Even/odd/none None
Flow control
RS/CS control
XON/XOFF control
None
None
Select the required menu option from the System Menu by following the procedure
given below.
Select “Maintenance Mode”.
Select “Memory Switches”.
Press “NEXT PAGE”.
If the RS-232C has been se-
lected, the host link speed set-
ting does not make any effect.
