Switch Mode Power Supply S8VS 5
Power ratings 120 W 180 W 240 W
Type
Item
Standard Maintenanc
e forecast
monitor
Total run
time
monitor
Standard Maintenanc
e forecast
monitor
Total run
time
monitor
Standard Maintenanc
e forecast
monitor
Total run
time
monitor
Efficiency (typical) 80% min. (87% typ.) 80% min. (88% typ.) 80% min. (86% typ.)
Input Voltage 100 to 240 VAC (85 to 264 VAC)
Frequency 50/60 Hz (47 to 63 Hz)
Current 100 V input 1.9 A max. 2.9 A max. 3.8 A max.
200 V input 1.1 A max. 1.6 A max. 2.0 A max.
230 V input (0.6 A typ.) (0.9 A typ.) (1.2 A typ.)
Power factor 0.95 min.
Harmonic current emissions Conforms to EN61000-3-2
Leakage current 100 V input 0.5 mA max.
200 V input 1.0 mA max.
230 V input (0.43 mA typ.) (0.45 mA typ.) (0.45 mA typ.)
Inrush current
(See note 1.)
100 V input 25 A max. (for a cold start at 25°C)
200 V input 50 A max. (for a cold start at 25°C)
230 V input (41 mA typ.) (34 mA typ.) (39 mA typ.)
Output Voltage adjustment range (See note 2.) −10% to 15% (with V.ADJ) (guaranteed) ±10% (with V.ADJ) (guaranteed)
Ripple 2.0% (p-p) max. (at rated input/output voltage)
f=20MHz measuring
(0.66%(p-p) typ.) (0.45%(p-p) typ.) (0.13%(p-p) typ.)
f=100MHz measuring
(0.67%(p-p) typ.) (0.52%(p-p) typ.) (0.21%(p-p) typ.)
Input variation influence 0.5% max. (at 85 to 264 VAC input, 100% load)
Load variation influence (rated input voltage)
1.5% max. (with rated input, 0 to 100% load)
Temperature variation influence 0.05%/°C max.
Start up time (See note 1.) 1,000 ms max. (at rated input/output voltage)
(380 ms typ.) (530 ms typ.) (780 ms typ.)
Hold time (See note 1.) 20 ms min. (at rated input/output voltage)
at 100% load (60 ms typ.) (60 ms typ.) (30 ms typ.)
Addition-
al func-
tions
Overload protection (See note 1.) 105% to 160% of rated load current, voltage drop, intermittent, automatic reset 105% to 160% of rated load
current, voltage drop, auto-
matic reset
Overvoltage protection (See notes 1 and 3.) Ye s
Output voltage indication (See note 4.) No Yes (selectable)
(See note 5.)
No Yes (selectable)
(See note 5.)
No Yes (selectable)
(See note 5.)
Output current indication (See note 4.) No Yes (selectable)
(See note 6.)
No Yes (selectable)
(See note 6.)
No Yes (selectable)
(See note 6.)
Peak-hold current indication (See note 4.) No Yes (selectable)
(See note 7.)
No Yes (selectable) (See note
7.)
No Yes (selectable)
(See note 7.)
Maintenance forecast monitor indication
(See note 4.)
No Yes
(selectable)
No No Yes
(selectable)
No No Yes
(selectable)
No
Maintenance forecast monitor output No Yes
(open collec-
tor output),
30 VDC
max., 50 mA
max.
(See note 8.)
No No Yes
(open collec-
tor output),
30 VDC
max., 50 mA
max.
(See note 8.)
No No Yes
(open collec-
tor output),
30 VDC
max., 50 mA
max.
(See note 8.)
No
Total run time monitor indication
(See note 4.)
No Yes
(selectable)
No Yes
(selectable)
No Yes
(selectable)
Total run time monitor output No Yes (open
collector out-
put), 30 VDC
max., 50 mA
max.
(See note 8.)
No Yes (open
collector out-
put), 30 VDC
max., 50 mA
max.
(See note 8.)
No Yes (open
collector out-
put), 30 VDC
max., 50 mA
max.
(See note 8.)
Undervoltage alarm indication (See note 4.) No Yes (selectable) No Yes (selectable) No Yes (selectable)
Undervoltage alarm output terminals No Yes (open collector output),
30 VDC max., 50 mA max.
(See note 8.)
No Yes (open collector output),
30 VDC max., 50 mA max.
(See note 8.)
No Yes (open collector output),
30 VDC max., 50 mA max.
(See note 8.)
Parallel operation No
Series operation Yes for up to 2 Power Supplies (with external diode)
Other Operating ambient temperature Refer to the derating curve in Engineering Data. (with no icing or condensation)
Storage temperature −25 to 65°C
Operating ambient humidity 25% to 85% (Storage humidity: 25% to 90%)
Dielectric strength 3.0 kVAC for 1 min. (between all inputs and outputs/ alarm outputs; detection current: 20 mA)
2.0 kVAC for 1 min. (between all inputs and PE terminals; detection current: 20 mA)
1.0 kVAC for 1 min. (between all outputs/ alarm outputs and PE terminals; detection current: 20 mA)
500 VAC for 1 min. (between all outputs and alarm outputs; detection current: 20 mA)
Insulation resistance 100 MΩ min. (between all outputs/ alarm outputs and all inputs/ PE terminals) at 500 VDC
Vibration resistance 10 to 55 Hz, 0.375-mm single amplitude for 2 h each in X, Y, and Z directions
10 to 150Hz, 0.35-mm single amplitude (5 G max.) for 80 min each in-X, Y, and Z directions
Shock resistance
150 m/s
2
, 3 times each in ±X, ±Y, and ±Z directions
Output indicator Yes (color: green)
EMI Conducted
Emissions
Conforms to EN61204-3 EN55011 Class A and based on FCC Class A
Conforms to EN61204-3 EN55011 Class B (See note 9.)
Radiated
Emissions
Conforms to EN61204-3 EN55011 Class A
Conforms to EN61204-3 EN55011 Class B (See note 9.)
EMS Conforms to EN61204-3 high severity levels
Approved standards UL: UL508 (Listing), UL60950
cUL: CSA C22.2 No.14, No.60950
EN/VDE: EN50178 (=VDE0160), EN60950 (=VDE0805)
SELV (EN60950/UL50178/UL60950-1)
According to VDE0106/P100, IP20
Weight 550 g max. 850 g max. 1,150 g max.
