Datasheet

5
Dimensions
Note: All units are in millimeters unless otherwise indicated.
■ Accessories (Order Separately)
Connection Sockets
93
+1
0
141
+1
0
189
+1
0
237
+1
0
285
+1
0
Qty. 2 3 4 5 6
L
48 x 48
44.8 x 44.8
Panel Cutout
Note: 1. Recommended panel thickness is 1 to 4 mm.
2. Close side-by-side mounting is possible (in a single direction).
Panel
Y92F-30 Flush-mounting adapter
Tightening screw
(96)
Terminal Arrangement
(Bottom View)
Dimensions with Flush-mounting Adapter (Accessory),
and Back Connecting Socket (Sold Separately)
Flush-mounting
adapter
P3G-08 Back
connecting socket
Side-by-side Mounting
of N Controllers
60 min.
P2CF-08 Front Connecting Socket
Mounting Holes
70 max.
Eight, M3.5 x 7.5 sems
50 max.
20 max.
Two, 4.5 dia. or two, M4
P3G-08 Back Connecting Socket (for Flush Mounting)
27 dia.
Two,
4.5-dia.
holes
Terminal Arrangement/
Internal Connections
(Top View)
Note: Can also be
mounted to a
DIN track.
Terminal Arrangement/
Internal Connections
(Bottom View)
Note: A finger-protection model (P2CF-08-E) is also available.
Note: A Protective Cover for finger protection (Y92A-48G) is also available.
