Datasheet

Standard Models (Power supply: 100-240 VAC)

■ Accessories (Order Separately)

Sockets

Protective Cover

Indication method No indication

Control method ON/OFF Proportional (P)

Input Output Relay

Input/

standard

scale (°C)

Thermocouple K (CA)

Chromel vs. Alumel

0 to 200°C E5C2-R20K AC100-240 0-200 E5C2-R40K AC100-240 0-200

0 to 300°C – E5C2-R40K AC100-240 0-300

0 to 400°C E5C2-R20K AC100-240 0-400 E5C2-R40K AC100-240 0-400

0 to 600°C E5C2-R20K AC100-240 0-600 E5C2-R40K AC100-240 0-600

0 to 800°C E5C2-R20K AC100-240 0-800 E5C2-R40K AC100-240 0-800

0 to 1000°C E5C2-R20K AC100-240 0-1000 –

0 to 1200°C E5C2-R20K AC100-240 0-1200 –

J (IC)

Iron versus Constantan

0 to 200°C E5C2-R20J AC100-240 0-200 –

0 to 300°C E5C2-R20J AC100-240 0-300 –

0 to 400°C E5C2-R20J AC100-240 0-400 –

Resistance

thermometer

Platinum resistance

thermometer

–50 to 50°C E5C2-R20P-D AC100-240 -50-50 –

0 to 50°C E5C2-R20P-D AC100-240 0-50 –

0 to 100°C E5C2-R20P-D AC100-240 0-100 –

0 to 200°C E5C2-R20P-D AC100-240 0-200 –

0 to 300°C E5C2-R20P-D AC100-240 0-300 –

0 to 400°C E5C2-R20P-D AC100-240 0-400 –

Thermistor THE

(replaceable element)

0 to 100°C E5C2-R20G AC100-240 0-100 –

100 to 200°C E5C2-R20G AC100-240 100-200 –

150 to 300°C E5C2-R20G AC100-240 150-300 –

Name Model

Front Connecting Socket P2CF-08

Back Connecting Socket P3G-08

Front Connecting Socket with Finger Protection P2CF-08-E

Protective Cover (for finger protection) Y92A-48G

Type Model

Hard Protective Cover Y92A-48B
