Datasheet

E2B
14
Dimensions
Note: All units are in millimeters unless otherwise indicated.
M8 Size
Pre-wired Models (Shielded)
Short Body
Pre-wired Models (Unshielded)
Long Body
Connector Models (Shielded)
Short Body
Connector Models (Unshielded)
Long Body
M8×P1
Two,clamping nuts
Operating indicator
(yellow LED,4×90°)
4-dia. vinyl-insulated round cable with 3 conductors
(conductor cross section : 0.141 mm² ;
insulator diameter : 0.85 mm) ; standard length : 2 m
Toothed washer
13
27
4
42
E2B-S08KS01-WP-@@/E2B-S08KS02-WP-@@
M8×P1
Operating indicator
(yellow LED,4×90°)
Two,clamping nuts
4-dia. vinyl-insulated round cable with 3 conductors
(conductor cross section : 0.141 mm² ;
insulator diameter : 0.85 mm) ; standard length : 2 m
6
27
4
42
6.6 dia.
13
Toothed washer
E2B-S08KN02-WP-@@/E2B-S08KN04-WP-@@
M8×P1
Two,clamping nuts
Operating indicator
(yellow LED,4×90°)
4-dia. vinyl-insulated round cable with 3 conductors
(conductor cross section : 0.141 mm² ;
insulator diameter : 0.85 mm) ; standard length : 2 m
13
49
4
64
Toothed washer
E2B-S08LS01-WP-@@/E2B-S08LS02-WP-@@
M8×P1
Two,clamping nuts
Operating indicator
(yellow LED,4×90°)
4-dia. vinyl-insulated round cable with 3 conductors
(conductor cross section : 0.141 mm² ;
insulator diameter : 0.85 mm) ; standard length : 2 m
13
6.6 dia.
49
4
64
6
Toothed washer
E2B-S08LN02-WP-@@/E2B-S08LN04-WP-@@
M8×P1
Two,clamping nuts
Operating indicator
(yellow LED,4×90°)
M8×P1
27
4
44
13
Toothed washer
E2B-S08KS01-MC-@@/E2B-S08KS02-MC-@@
13
M8×P1
Two,clamping nuts
M8×P1
Operating indicator
(yellow LED,4×90°)
6
44
27
4
6.6 dia.
Toothed washer
E2B-S08KN02-MC-@@/E2B-S08KN04-MC-@@
M8×P1
Operating indicator
(yellow LED,4×90°)
Two,clamping nuts
M8×P1
13
49
4
66
Toothed washer
E2B-S08LS01-MC-@@/E2B-S08LS02-MC-@@
M8×P1
Operating indicator
(yellow LED,4×90°)
Two,clamping nuts
M8×P1
13
49
4
66
6
6.6 dia.
Toothed washer
E2B-S08LN02-MC-@@/E2B-S08LN04-MC-@@
Mounting Hole Cutout Dimensions
External diameter
of Proximity Sensor
Dimension F (mm) Dimension G (mm)
M8
GF
8.5 dia.
+0.5
0
13
