Datasheet

CP1L
9
Built-in input terminals
60 (36 inputs,
24 outputs)
40 (24 inputs,
16 outputs)
30 (18 inputs,
12 outputs)
20 (12 inputs,
8 outputs)
14 (8 inputs,
6 outputs)
10 (6 inputs,
4 outputs)
Number of connectable
Expansion Units and
Expansion I/O Units
CP-series Expansion Unit and Expansion I/O Units: 3 max.
CP-series Expansion Units and Expansion
I/O Units: 1 max.
Not supported.
Max. number of I/O points
180 (60 built in + 40
per Expansion (I/O)
Unit × 3 Units)
160 (40 built in + 40
per Expansion (I/O)
Unit × 3 Units)
150 (30 built in + 40
per Expansion (I/O)
Unit × 3 Units)
60 (20 built in + 40
per Expansion (I/O)
Unit × 1 Unit)
54 (14 built in + 40
per Expansion (I/O)
Unit × 1 Unit)
10 (10 built in)
Interrupt inputs 6 inputs (Response time: 0.3 ms)
4 inputs (Response
time: 0.3 ms)
2 inputs (Response
time: 0.3 ms)
Interrupt inputs counter
mode
6 inputs (Response frequency: 5 kHz max. for all interrupt inputs), 16 bits
Up or down counters
4 inputs (Response
frequency:
5 kHz max. for all
interrupt inputs),
16 bits
Up or down
counters
2 inputs (Response
frequency:
5 kHz max. for all
interrupt inputs),
16 bits
Up or down
counters
Quick-response inputs 6 points (Min. input pulse width: 50 μs max.)
4 points (Min. input
pulse width: 50 μs
max.)
2 points (Min. input
pulse width: 50 μs
max.)
Scheduled interrupts 1
High-speed counters
4 inputs/2 axes (24 VDC): Differential phases (4x), 50 kHz
Single-phase (pulse plus direction, up/down, increment), 100 kHz
Value range: 32 bits, Linear mode or ring mode
Interrupts: Target value comparison or range comparison
Pulse outputs
(models with
transistor out-
puts only)
Pulse
outputs
Trapezoidal or S-curve acceleration and deceleration (Duty ratio: 50% fixed)
2 outputs, 1 Hz to 100 kHz (CCW/CW or pulse plus direction)
PWM
outputs
Duty ratio: 0.0% to 100.0% (specified in increments of 0.1% or 1%)
2 outputs, 0.1 to 6553.5 Hz or 1 to 32,800 Hz (Accuracy: +1%/0% at 0.1 Hz to 10,000 Hz and +5%/0% at 10,000 Hz to 32,800 Hz)
Analog control 1 (Setting range: 0 to 255)
Analog input 1 input (Resolution: 1/256, Input range: 0 to 10 V). Not isolated.
Type
CP1L-M60
(60 points)
CP1L-M40
(40 points)
CP1L-M30
(30 points)
CP1L-L20
(20 points)
CP1L-L14
(14 points)
CP1L-L10
(10 points)
Item Models CP1L-M60@@-@ CP1L-M40@@-@ CP1L-M30@@-@ CP1L-L20@@-@ CP1L-L14@@-@ CP1L-L10@@-@
