Datasheet

CP1L
8
● CP1L CPU Unit (M/L Type)
Pulse outputs
(models with
transistor outputs
only)
Pulse outputs
Trapezoidal or S-curve acceleration and deceleration (Duty ratio: 50% fixed)
2 outputs, 1 Hz to 100 kHz (CCW/CW or pulse plus direction)
PWM outputs
Duty ratio: 0.0% to 100.0% (specified in increments of 0.1% or 1%)
2 outputs, 0.1 to 6553.5 Hz or 1 to 32,800 Hz
(Accuracy: +1%/0% at 0.1 Hz to 10,000 Hz and +5%/0% at 10,000 Hz to 32,800 Hz)
Analog input 2 input (Resolution: 1/1000, Input range: 0 to 10 V). Not isolated.
Type
CP1L-M60
(60 points)
CP1L-M40
(40 points)
CP1L-M30
(30 points)
CP1L-L20
(20 points)
CP1L-L14
(14 points)
CP1L-L10
(10 points)
Item Models CP1L-M60@@-@ CP1L-M40@@-@ CP1L-M30@@-@ CP1L-L20@@-@ CP1L-L14@@-@ CP1L-L10@@-@
Control method Stored program method
I/O control method Cyclic scan with immediate refreshing
Program language Ladder diagram
Function blocks
Maximum number of function block definitions: 128 Maximum number of instances: 256
Languages usable in function block definitions: Ladder diagrams, structured text (ST)
Instruction length 1 to 7 steps per instruction
Instructions Approx. 500 (function codes: 3 digits)
Instruction execution time Basic instructions: 0.55 μs min. Special instructions: 4.1 μs min.
Common processing time 0.4 ms
Program capacity 10K steps 5K steps
Number of tasks 288 (32 cyclic tasks and 256 interrupt tasks)
Scheduled inter-
rupt tasks
1 (interrupt task No. 2, fixed)
Input interrupt
tasks
6 (interrupt task No. 140 to 145, fixed)
4 (interrupt task No.
140 to 143, fixed)
2 (interrupt task No.
140 to 141, fixed)
(Interrupt tasks can also be specified and executed for high-speed counter interrupts and executed.)
Maximum subroutine number 256
Maximum jump number 256
I/O
areas
Input Area 1,600 bits (100 words) CIO 0 to CIO 99
Built-in Input
Area
36 bits: CIO 0.00 to
CIO 0.11 and CIO
1.00 to CIO 1.11 and
CIO 2.00 to CIO 2.11
24 bits: CIO 0.00 to
CIO 0.11 and CIO
1.00 to CIO 1.11
18 bits: CIO 0.00 to
CIO 0.11 and CIO
1.00 to CIO 1.05
12 bits: CIO 0.00 to
CIO 0.11
8 bits: CIO 0.00 to
CIO 0.07
6 bits: CIO 0.00 to
CIO 0.05
Output Area 1,600 bits (100 words) CIO 100 to CIO 199
Built-in
Output Area
24 bits: CIO 100.00
to CIO 100.07 and
CIO 101.00 to CIO
101.07 and CIO
102.00 to CIO 102.07
16 bits: CIO 100.00
to CIO 100.07 and
CIO 101.00 to CIO
101.07
12 bits: CIO 100.00
to CIO 100.07 and
CIO 101.00 to CIO
100.03
8 bits: CIO 100.00
to CIO 100.07
6 bits: CIO 100.00
to CIO 100.05
4 bits: CIO 100.00
to CIO 100.03
1:1 Link Area 256 bits (16 words): CIO 3000.00 to CIO 3015.15 (CIO 3000 to CIO 3015)
Serial PLC Link
Area
1,440 bits (90 words): CIO 3100.00 to CIO 3189.15 (CIO 3100 to CIO 3189)
Work bits
8,192 bits (512 words): W000.00 to W511.15 (W0 to W511)
CIO Area: 37,504 bits (2,344 words): CIO 3800.00 to CIO 6143.15 (CIO 3800 to CIO 6143)
TR Area 16 bits: TR0 to TR15
Holding Area 8,192 bits (512 words): H0.00 to H511.15 (H0 to H511)
AR Area
Read-only (Write-prohibited): 7168 bits (448 words): A0.00 to A447.15 (A0 to A447)
Read/Write: 8192 bits (512 words): A448.00 to A959.15 (A448 to A959)
Timers 4,096 timer numbers: T0 to T4095
Counters 4,096 counter numbers: C0 to C4095
DM Area 32 Kwords: D0 to D32767 10 Kwords: D0 to D9999, D32000 to D32767
Data Register Area 16 registers (16 bits): DR0 to DR15
Index Register Area 16 registers (32 bits): IR0 to IR15
Task Flag Area 32 flags (32 bits): TK0000 to TK0031
Trace Memory 4,000 words (500 samples for the trace data maximum of 31 bits and 6 words.)
Memory Cassette A special Memory Cassette (CP1W-ME05M) can be mounted. Note: Can be used for program backups and auto-booting.
Clock function
Supported. Accuracy (monthly deviation): −4.5 min to −0.5 min (ambient temperature: 55°C),
−2.0 min to +2.0 min (ambient temperature: 25°C), −2.5 min to +1.5 min (ambient temperature: 0°C)
Communications functions
One built-in peripheral port (USB 1.1): For connecting Support Software only.
A maximum of two Serial Communications Option Boards can be
mounted.
A maximum of one Serial Communications
Option Board can be mounted.
Not supported.
A maximum of two Ethernet Option Board can be mounted.
When using CP1W-CIF41 Ver.1.0, one Ethernet Option Board
can be mounted.
A maximum of one Ethernet Option Board
can be mounted.
Not supported.
Memory backup
Flash memory: User programs, parameters (such as the PLC Setup), comment data, and the entire DM Area can be saved to flash
memory as initial values.
Battery backup: The Holding Area, DM Area, and counter values (flags, PV) are backed up by a battery.
Battery service life
Service life expectancy is 5 years at 25°C, less at higher temperatures. (From 0.75 to 5 years depending on model, power supply
rate, and ambient temperature.)
Type CP1L-EM40 (40 points) CP1L-EM30 (30 points) CP1L-EL20 (20 points)
Item Models CP1L-EM40D@-@ CP1L-EM30D@-@ CP1L-EL20D@-@
