■ Built-in Output Area
Number of
outputs
Output Terminal
Block
When the
instructions to
the right are not
executed
When a pulse output instruction
(SPED, ACC, PLS2, or ORG) is executed
When the origin search function is
set to be used in the PLC Setup,
and an origin search is executed
by the ORG instruction
When the PWM
instruction is
executed
Word Bit Normal output
Fixed duty ratio pulse output
Variable duty ratio
pulse output
CW/CCW Pulse plus direction
When the origin search function
is used
PWM output
CPU Units with
14 to 60 points
CPU Units
with 10 point
10
CIO 100
00
Normal output 0 Pulse output 0 (CW) Pulse output 0 (pulse) --- --- ---
01
Normal output 1 Pulse output 0 (CCW) Pulse output 0 (direction) --- --- PWM output 0
02
Normal output 2 Pulse output 1 (CW) Pulse output 1 (pulse) --- --- ---
03
Normal output 3 Pulse output 1 (CCW) Pulse output 1 (direction) ---
Origin search 0
(Error counter
reset output)
PWM output 1
14
04
Normal output 4 --- ---
Origin search 0
(Error counter
reset output)
--- ---
05
Normal output 5 --- ---
Origin search 1
(Error counter
reset output)
--- ---
20
06
Normal output 6 --- --- --- --- ---
07
Normal output 7 --- --- --- --- ---
30
CIO 101
00
Normal output 8 --- --- --- --- ---
to
to to to to to to
03
Normal output 11 --- --- --- ---
40
04
Normal output 12 --- --- --- ---
to
to to to to to to
07
Normal output 15 --- --- --- --- ---
60 CIO 102
01
Normal output 16 --- --- --- --- ---
to
to to to to to to
07
Normal output 23 --- --- --- --- ---
