SPECIFICATIONS:
Form: 040-12000-001D 11/07
Warning
The operating description in this Instruction Manual is
for use by qualified personnel only. To avoid electrical
shock, do not perform any servicing of this unit other
than that contained in the operating instructions, unless
you are qualified and certified to do so by Omnitron
Systems Technology, Inc.
Warranty
This product is warranted to the original purchaser against
defects in material and workmanship for a period of
TWO YEARS from the date of shipment. A LIFETIME
warranty may be obtained by the original purchaser by
REGISTERING this product with Omnitron within 90
days from the date of shipment. TO REGISTER,
COMPLETE AND MAIL OR FAX THE ENCLOSED
REGISTRATION FORM TO THE INDICATED
ADDRESS. Or you may register your product on the
Internet at http://www.omnitron-systems.com. During
the warranty period, Omnitron will, at its option, repair
or replace a product which is proven to be defective.
For warranty service, the product must be sent to an
Omnitron designated facility, at Buyer’s expense.
Omnitron will pay the shipping charge to return the
product to Buyer’s designated US address using
Omnitron’s standard shipping method.
Limitation of Warranty
The foregoing warranty shall not apply to defects
resulting from improper or inadequate use and/or
maintenance of the equipment by Buyer, Buyer-supplied
equipment, Buyer-supplied interfacing, unauthorized
modifications or tampering with equipment (including
removal of equipment cover by personnel not
specifically authorized and certified by Omnitron), or
misuse, or operating outside the environmental
specification of the product (including but not limited to
voltage, ambient temperature, radiation, unusual dust,
etc.), or improper site preparation or maintenance.
No other warranty is expressed or implied. Omnitron
specifically disclaims the implied warranties of
merchantability and fitness for any particular purpose.
Exclusive Remedies
The remedies provided herein are the Buyer’s sole and
exclusive remedies. Omnitron shall not be liable for
any direct, indirect, special, incidental, or consequential
damages, whether based on contract, tort, or any legal
theory.
TECHNICAL SUPPORT:
For help with this product, contact Omnitron’s Tech.
Support:
Phone: [phone]
Fax: [phone]
Address: Omnitron Systems Technology, Inc.
140 Technology #500
Irvine, CA 92618 USA
E-mail: [e-mail]
URL: http://www.omnitron-systems.com
SPECIFICATIONS (CONT.):
TROUBLESHOOTING GUIDE:
Problem:
The Power LED does not illuminate after installation
is complete.
Possible Causes:
A. Confirm that the power supply is connected.
B. Confirm that the correct power supply is being used.
Problem:
The Fiber Optic link LED does not illuminate after installation
is complete.
Possible Causes:
A. Confirm that the fiber optic cable is properly connected
to the miConverter Gx and the remote fiber optic device.
B. Confirm that the fiber cable type matches the fiber
transceiver type (multimode, single-mode) on the
miConverter Gx.
C. If using a dual-fiber model, confirm that the transmitter
(Tx) is attached to the receiver side of its link partner, and
that the receiver (Rx) is attached to the transmitter.
D. If using a single-fiber model, confirm that the Tx
wavelength on the miConverter Gx matches the Rx of the
connected fiber optic device.
Problem:
The Fiber Optic link LED blinks slowly after installation is
complete, indicating connected devices are not able to
complete auto-negotiation.
Possible Causes:
A. Confirm that the miConverter Gx and the connected
fiber optic and UTP devices are set to auto-negotiation
mode. If the connected fiber device does not
support auto-negotiation, configure the miConverter to
MAN mode.
B. Confirm that the UTP cables of the miConverter Gx and
the connected fiber optic and UTP devices are properly
connected.
C. If two miConverter Gx converters are connected via
fiber, confirm that both converters have their fiber optic
ports set to auto-negotiate “AN” and their UTP ports
connected to remote devices.
D. Confirm that the connected UTP and fiber optic devices
have the same Duplex/Pause capabilities.
Problem:
The UTP link LED does not illuminate after installation is
complete.
Possible Causes:
A. Confirm that the UTP cable is connected properly to the
miConverter Gx and the attached UTP device.
B. Confirm that the UTP cable pin-out is correct
(EIA/TIA-568-A).
C. Confirm that the attached UTP device is working properly
and is capable of Gigabit Ethernet speed.
Note: If corrective actions do not resolve your situation,
please contact Omnitron Systems Technical Support.
Page 13
Description
1000BASE-T UTP to 1000BASE-X
Copper to Fiber Media Converter
with Auto-negotiation
Protocols
802.3ab, 1000BASE-T,
1000BASE-X
UTP Cable Type
EIA/TIA 568A/B
Category 5 and higher
Fiber Cable Type
Multimode: 50/125,
62.5/125, 100/140um
Single-mode: 9/125um
UTP Connector Type
RJ45
Fiber Connector Types
Single-Fiber: SC
Dual Fiber: ST, SC
Power Requirements
Minimum DC Power 0.5A @ 5VDC
DC Power Connector 2.5mm DC Jack - Center Positive
AC Power Adapter
[US]
100-120VAC/60Hz
0.03A @ 120VAC
AC Power Adapter
[Universal and
Country/Region Specific]
100-240VAC/50-60Hz
0.03A @ 120VAC
Dimension (WxDxH)
W:1.71" x L:4.10" x H:0.84"
Weight
without power adapter
5 oz.
with USB power adapter cable 6 oz.
with AC power adapter [US] 12 oz.
with AC power adapter
[Universal]
19 oz.
Compliance
UL, CE, FCC Class A
Temperature
Operational 0 to +50
o
C
Storage -50 to +80
o
C
Humidity
(non-condensing)
5% to 95%
Altitude [ft]
-100m to 4000m
MTBF [hrs]
without power adapter 810,000
with US and
Country/Region Specific
power adapter
250,000
with Universal power adapter 100,000
