1.0 INTRODUCTION
1.1 General Description
The 6540-FK is the direct replacement for the discontinued FlexSwitch Model
600XC 2Fx + 2U. The 6540-FK replacement kit consists of two iConverter
10/100Base-Tx to 100Base-Fx Media Converter Modules installed in a iConverter
2-Module chassis.
The 6540-FK provides two 10/100 auto-negotiating UTP ports with auto-crossover
and two 100Base-Fx fiber ports.
The two 100Base-Fx fiber ports support half or full duplex operation.
The 6540-FK features front panel accessible DIP-Switches for convenient
configuration of the single UTP and fiber port. On-board DIP-Switches
configure the link mode and backplane operation. The backplane is enabled
by default.
1.2 Chassis Models
FlexSwitch Replacement Matrix
Discontinued Part Replacement Part
6540-0 6540-0-FK
6540-2 6540-2-FK
6540-3 6540-3-FK
6541-0 6541-0-FK
6541-2 6541-2-FK
Replacement Matrix
FlexSwitch Model 6540
Fiber Type Distance
Connector Type
SC ST
MM 5km 6540-0-FK 6541-0-FK
SM 30km 6540-2-FK 6541-2-FK
SM 60km 6540-3-FK -
Model Numbers
