Owner's manual

inches (mm)
800.MOUNT.IT (800.668.6848)08112010
75/100 FD line drawing
3.9 (100)
3.9 (100)
3.0 (75)
3.0 (75)
1.0 (25)
2.6 (65)
4.0 (102)
2.0 (51)
0.9 (23)
5.8 (147)
10.5 (267)
11.0 (279)
0.5 (13)
90˚
105˚
