Color Stock Code Packaging UPC MC UPC
Americas
Black 1003693-1 728901020117 728901713552
International
Black 1003694-1 728901020124 728901713569
Americas
Platinum 1000937-1 728901007255 728901700743
International
Platinum 1001910-1 728901013133 728901706219
Fits most: 13” - 24” flat panels
Supports up to: 40 lbs (18.1 kg)
Tilt: Up to 90º
Pan: 360º
VESA compliant: 75x75 and 100x100
UL listed: Yes
Warranty: 5 years
Color: Platinum
• Folds up when not in use
• Tilt and pan for multiple viewing angles
• Simple to install and use
• Includes complete hardware kit
75/100 FD technical data sheet
OmniMount, an innovator of A/V mounts and furniture for
more than a quarter century, is the choice of professional
installers and the brand most recommended by flat
panel manufacturers. The Classic Series is a full line of
fixed, tilt, flip down and full motion mounting solutions
designed with simplicity and reliability in mind. The
75/100 FD is a small flip down mount that is the
obvious choice for basic under cabinet installations.
Dimensions WxDxH inches (mm) Wt lbs (kg)
Product Box
4.6 x 11.4 x 1.7 (118x289x44) 2.2 (1)
Master Carton
5.3 x 12 x 7.5 (350x160x170) 8.8 (4)
Box Contents Qty
Flip down mount 1
Complete mount installation hardware kit 1
Complete panel attachment hardware kit 1
Instruction manual 1
Flat panel compatibility chart 1
