This submenu provides level adjustments for the audio inputs and the absolute peak operating level of the Analog,
AES-3 (AES/EBU) and Livewire outputs. Choices governing the selection of the input audio source (Analog, AES
Digital or Livewire) and signal mode (Stereo or Mono) are also found within these submenus.
These I/O settings are generally “set once and forget” parameters, usually adjusted during initial installation and
then left alone. These I/O settings are
not saved with a processing preset but can be saved, loaded, deleted or
renamed as “I/O Configurations” using options available in this submenu.
Please note that Livewire functionality is not yet implemented in the current software but will be available with a
free downloadable software update. Please check the Omnia website for new software announcements, download
links and manual updates at:
http://www.omniaaudio.com/
Mtr Select (Meter Select)
Selects whether the Input levels, Analog Output levels or AES/EBU Digital Output levels are displayed on the
front panel L & R LED bargraph meters.
Input
There are nine controls under the heading “Input” and each will be explained in the order in which they appear
in the menu:
<-Exit
Click on this option to return to the Input/Output menu.
Input Src (Input Source)
Allows the selection of Analog or AES/EBU (digital) as the primary input source to the
OmniaONE.
Fover Time (Failover Time)
Failover Time is a feature that when set to a value other than zero (disabled) allows the
OmniaONE to automatically select another input source if the currently selected one fails.
Failover Time is the amount of time that will elapse after the failure of audio on the primary input
source before the unit makes the decision to switch to the secondary (failover) input source. For
instance, if Failover Time is set for 5 seconds and the primary audio source fails, 5 seconds later
the unit will switch to the secondary audio input if that input is active. If, at any time, audio is
restored on the primary input (for 1 second, continuously), the unit will switch back to the primary
audio input. It will remain with the primary input unless another failure is detected.
Fover Src (Failover Source)
Failover Source selects which audio input: Analog or AES/EBU (digital), will serve as the
secondary audio input. Note that the audio input that is selected under Input Source (above) will
always be the Primary audio input. A source selected under Failover Source will always be the
secondary source.
Anlg Level (Analog Level)
Adjusts the master audio input level for the analog inputs which are derived from the rear panel
XLR female input connectors. (See
Proper Setting of Input Levels on Page 26)
