4.3.7 Configuration (continued)
Channel: Choose the operation channel defined in IEEE 802.15.4 for the sensor network.
This allows you to select a wireless channel to communicate with the End Devices. It is
strongly suggested to let the Coordinator to search for the best channel automatically, and by
not touching this field.
Transmit Power Range: This determines the signal power transmitted by the Receiver.
The options are 10dBm and 20dBm.
Refer to your local regulations for the allowed maximum transmit power.
Reset Network: Power resets the radio module in the Coordinator.
4.3.8 Sensor Setup
Click on from the Home Page, the following page will appear. Select the
proper Group.
Figure 4.17 Sensor Setup by Group
The Sensor Setup Page is for configuring End Device parameters such as name and
update rate.
A faster update period consumes more energy and creates more traffic. The
update time must be selected to satisfy acceptable network performance and
desired battery lifetime.
SENSOR SETUP: BY GROUP
SENSOR SETUP
http://192.168.1.200
Address
Main Menu
Wireless Sensors ID: 0 - 7
Wireless Sensors ID: 8 - 15
Wireless Sensors ID: 16 - 23
Wireless Sensors ID: 24 - 31
Sensor Setup
Group A
Group B
Group C
Group D
Sensor Setup
