4.3.7 Configuration
Click on from the Home Page, the following page will appear.
Figure 4.16 Configuration
Name: Coordinator name [maximum of 16 alphanumeric characters]
Temperature: Unit of temperature readings, [ ºC or ºF ].
Pressure: Unit of pressure readings [ mbar, inHg or mmHg ].
TCP Connections: Number of TCP connections available for data query. If “0” is
selected no TCP connection can be made to the indicated port number [ 0 through 5 ].
Port: Port number for TCP connections. [invalid ports: <500, >65536, 1000, 1001 ].
Save: Saves any changes on the Configuration page.
Reset: This will put the previous values back in the fields if Save button is not yet clicked.
Version
: Firmware version of the radio module, also shown on model/serial label.
PID
: The Personal Network ID is automatically detected and displayed.
CONFIGURATION
CONFIGURATION
http://192.168.1.200
Address
Main Menu
Name zSeries
Reset Network
Temperature C Pressure mbar
TCP Connections 1 Port 02000
Save Reset
Channel
Set Radio
11
PID 13111
Version x.x
Transmit Power Range 20dBm
Please refer to local regulation for maximum transmit power range
Configuration
