- OMEGA Peristaltic Pump User Guide

Specifications

9-3

Table 9-2. Average Flow Rates (Cont’d)

Tubing Wall Tubing Size mL per Minimum Flow Maximum Flow

Thickness Inner Diameter Revolution Rate at 600 RPM Rate at 600 RPM

(mL/Minute) (mL/Minute)

1.5 mm 3.0 mm 0.8* 8 482

1.5 mm 4.0 mm 1.43* 15 857

1.5 mm 5.0 mm 2.1* 21 1257

1.5 mm 6.0 mm 2.7* 27 1607

1.5 mm 7.0 mm 3.6* 37 2187

1.5 mm 8.0 mm 3.9* 39 2316

* Metric mL per Revolution numbers are rounded off

Normalized flow rates (mL per revolution) vary significantly, based on

motor speed, tubing materials, and mechanical tolerances in pump

dimensions. In addition, the variances are different for the different

tubing dimensions. Variances from the normalized flow rates of Table

9-2 are shown below. The data is shown for new tubing only.

Tubing operating life tests are done at 600 RPM, with 20°C water, 0 PSI

back pressure until the tubing breaks

Table 9-3. Variances in Normalized Flow Rate (mL per Revolution)

Tubing Size Due to Between Pumps Due to Different

Inner Diameter Motor (due to Mechanical Tubing Materials

(in.) Speed Tolerances)

⁄32 ±10% ±25% ±20%

⁄16 ±10% ±15% ±15%

⁄8 ±10% ±10% ±5%

⁄16 ±5% ±10% ±5%

⁄4 ±5% ±15% ±5%

⁄16 ±15% ±20% ±10%
