- OMEGA Peristaltic Pump User Guide

Parts of the Pump
2
2-3
2.3 Right Side of the Pump
Figure 2-3. View of the Right Side
Item Description Function
3 Clamp Plate Secures the tubing during pump operation
4 Clamp Screw Adjusts the tubing clamp position
5 Rotor Shaft Main drive shaft for the pump
7 Lower Shield Shields the tubing, supports the Rotor Assembly
8 Base Mounting surface to attach the pump to the motor,
supports the Rotor Assembly
8
3
57
4
