OLIMEX© 2012 MOD-RTC User's Manual
CHAPTER 5
CONTROL CIRCUITY
5. Introduction to the chapter
Here you can find information about reset circuit and quartz crystal locations.
5.1 Reset
The module lacks hardware reset.
5.2 Clock
Real time clock (RTC) Q2 is found at pins 1 and 2 of the PCF8563.
