Datasheet

M1X STRIKER
Variable-output dual-switch LED ashlight
olightworld.com
All performance claims to ANSI/NEMA FL1-2009 Standard. Made in China.
© Olight 5/20/15 V1
FEATURES
• Five brightness levels from 0.5 to 1000 lumens, plus a strobe mode
• The light features a maximum beam distance up to 190m and a maximum Runtime of 360hrs.
• Shockproof body and enhanced conductivity tail cap structure
• The tail switch has a momentary ON-OFF functionality, supporting the high output and strobe mode functions for
tactical use. The light brightness level and strobe mode can be activated through the side switch
• The side switch features a battery power indicator that glows red when the power runs low
• There is a 99% light transmittance rate through the tempered glass lens that has a two-sided anti-reective coating
• The M1X Striker has a built in thermal management system that limits the high output to 5 minutes and then gradually
ramps down the high output by 55% after 3 minutes of constant use
• Reverse polarity protection to prevent improper battery installation
• IPX8 water-proof capability
LENS
Tough ultra-clear tempering glass with
anti-reective coating
LIGHT SOURCE
1 x Cree XM-L2 CW
DIMENSIONS
Length: 5.35 in / 136 mm
Bezel Diameter: 1.02 in / 26mm
Weight: 2.82 oz / 80 g (excluding batteries)
BODY MATERIAL
Aircraft-grade aluminum body with anti-scratch
type III hard anodizing
BATTERY SOURCE
2 x CR123A/RCR123A or 1 x 18650
WARRANTY
Olight’s 5 Year warranty.
Visit olightworld.com/warranty
ACCESSORIES
• Lanyard x1
• CR123A/RCR123A Battery Magazine x1
• Spare O-rings x 2
• User Manual x1
OUTPUT
WATERPROOF
IPX 8
DROP TEST COMPLIANCE
1.5 m
2 m
Also includes Strobe Mode: 10Hz / 1000 lumens
FL1 STANDARD MODE 1 MODE 2 MODE 3 MODE 4 MODE 5
1000
LUMENS
350
LUMENS
60
LUMENS
10
LUMENS
0.5
LUMENS
5min +
55min(60%)
2 h 12 h 60 h 360 h
190 m
9,000 cd
m
