3. Basic Operations
Names of Components
The chapter describes the name of each component.
• Front View
•Rear View
• Inside of the machine
Front View
Symbol Name
a Operator panel
Basic Operations on the Operator Panel
bUSB port
c MP tray (Multipurpose tray)
d Open button
e Output tray (top cover)
f Wireless LAN module cover
g Paper supporter
h Envelope lever (Use this when printing on envelopes. For instructions, refer to the Advanced
Manual.)
