Settings
7
HDD Backup Utility 7-9
Detail dialog box
If the [Detail] button in the Register from IP address dialog box or Edit dialog
box is clicked, the following dialog box appears.
The number of the port used with the TCP socket interface can be changed.
Specify the same settings as those specified on the multifunctional product.
10 [OK] button Applies the changes to the settings, and displays the Device
Registration dialog box again.
11 [Cancel] button Displays the Device Registration dialog box again without
saving the changes to the settings.
No. Item Name Description
1
2
4
3
6
5
No. Item Name Description
1 Port number Specify the port used with the TCP socket interface.
The default value is 59158.
2 SSL port number Specify the number of the port used with the TCP socket in-
terface during SSL transmissions.
The default value is 59159.
3 [Reset] button Resets the port numbers to their default settings.
4 [Help] button Displays the online Help.
5 [OK] button Applies the changes to the settings, and displays the previ-
ous dialog box again.
6 [Cancel] button Displays the previous dialog box again without saving the
changes to the settings.
