Instructions for use

- EN -
23
Technical data
Description
Filtral
1500
3000
6000
Rated voltage
V AC
230
230
230
Rated frequency
Hz
50
50
50
Power consumption
W
18
36
52
Performance of UVC lamp TC-S
W
5
9
11
Hose connection for
branch valve
mm
13
–
–
Stepped hose
adapter
mm
–
13/19/25
13/19/25
Max. conveying performance
l/h
560
1200
1700
Max. water column
m
0.9
1.8
2.1
Air conveying perfor-
mance of the Venturi noz-
zle with a 1.5 m hose with
a submerged depth of
0 m
l/h
50
1)
116
218
0.2 m
l/h
28
1)
90
145
0.3 m
l/h
21
1)
72
123
0.4 m
l/h
–
69
114
0.6 m
l/h
–
58
99
0.8 m
l/h
–
33
81
1.0 m
l/h
–
–
59
1.2 m
l/h
–
–
31
Filter surface
cm²
301
440
697
Filter foam (blue)
Quantity
1
1
1
Pore size
ppi
10
10
10
Filter foam (red)
Quantity
1
1
1
Pore size
ppi
30
30
30
Number of bio surface elements
1
2
4
Number of bags of filter ceramic
1
1
1
Pond size (with fish)
m³
0.75
1.5
3
Pond size (without fish)
m³
1.5
3
6
Dimensions
Length
mm
207
269
347
Width
mm
228
245
276
Height
mm
130
140
157
Weight
kg
2.7
3.4
4.9
Length of the connection cable
m
10
10
10
1)
With optionally available Venturi nozzle
Symbols on the unit
Dust-tight. Watertight to 2 m depth.
Dangerous UVC radiation!
Remove the unit at temperatures below zero (centigrade).
Fragile, handle with care. Danger of cut injuries.
Do not dispose of together with household waste!
Read the operating instructions!
