NXP Semiconductors
PESD5V0L1UA/UB/UL
Low capacitance unidirectional ESD protection diodes
5. Limiting values
[1] Non-repetitive current pulse 8/20 µs exponential decay waveform according to IEC 61000-4-5.
[2] Measured from pin 1 to pin 2.
[1] Device stressed with ten non-repetitive ESD pulses.
Table 6. Limiting values
In accordance with the Absolute Maximum Rating System (IEC 60134).
Symbol Parameter Conditions Min Max Unit
P
PP
peak pulse power t
p
= 8/20 µs
[1][2]
-42W
I
PP
peak pulse current t
p
= 8/20 µs
[1][2]
- 3.5 A
T
j
junction temperature - 150 °C
T
amb
ambient temperature −55 +150 °C
T
stg
storage temperature −65 +150 °C
Table 7. ESD maximum ratings
T
amb
=25 ° C unless otherwise specified.
Symbol Parameter Conditions Min Max Unit
V
ESD
electrostatic discharge voltage IEC 61000-4-2
(contact discharge)
[1]
-26kV
machine model - 400 V
MIL-STD-883 (human
body model)
-10kV
Table 8. ESD standards compliance
Standard Conditions
IEC 61000-4-2; level 4 (ESD) > 15 kV (air); > 8 kV (contact)
MIL-STD-883; class 3 (human body model) > 4 kV
