NXP Semiconductors
PESD5V0L1UA/UB/UL
Low capacitance unidirectional ESD protection diodes
Reflow soldering is the only recommended soldering method.
Fig 12. Reflow soldering footprint PESD5V0L1UB (SOD523/SC-79)
Reflow soldering is the only recommended soldering method.
Fig 13. Reflow soldering footprint PESD5V0L1UL (SOD882)
solder lands
solder resist
occupied area
solder paste
Dimensions in mm
0.6
(2×)
0.5
(2×)
2.15
1.1
0.7
(2×)
0.8
(2×)
1.2
sod523_fr
solder lands
solder resist
occupied area
solder paste
sod882_fr
0.9
0.3
(2×)
R0.05 (8×)
0.6
(2×)
0.7
(2×)
0.4
(2×)
1.3
0.7
Dimensions in mm
