Philips Semiconductors Product specification
74LVC04A
Hex inverter
1997 Jun 30
4
RECOMMENDED OPERATING CONDITIONS
SYMBOL
PARAMETER
CONDITIONS
LIMITS
UNIT
SYMBOL
PARAMETER
CONDITIONS
MIN MAX
UNIT
V
CC
DC supply voltage (for max. speed performance) 2.7 3.6 V
V
CC
DC supply voltage (for low-voltage applications) 1.2 3.6 V
V
I
DC Input voltage range 0 5.5 V
V
O
DC output voltage range 0 V
CC
V
T
amb
Operating ambient temperature range in free-air –40 +85 °C
t
r
, t
f
Input rise and fall times
V
CC
= 1.2 to 2.7V
V
CC
= 2.7 to 3.6V
0
0
20
10
ns/V
ABSOLUTE MAXIMUM RATINGS
1
Absolute Maximum Rating System (IEC 134)
Voltages are referenced to GND (ground = 0V)
SYMBOL
PARAMETER CONDITIONS RATING UNIT
V
CC
DC supply voltage –0.5 to +6.5 V
I
IK
DC input diode current V
I
0 –50 mA
V
I
DC input voltage Note 2 –0.5 to +5.5 V
I
OK
DC output diode current V
O
V
CC
or V
O
 0 50 mA
V
O
DC output voltage Note 2 V
CC
+ 0.5 V
I
O
DC output source or sink current V
O
= 0 to V
CC
50 mA
I
GND
, I
CC
DC V
CC
or GND current 100 mA
T
stg
Storage temperature range –65 to +150 °C
Power dissipation per package
P
TOT
– plastic mini-pack (SO) above +70°C derate linearly with 8 mW/K 500
mW
– plastic shrink mini-pack (SSOP and TSSOP) above +60°C derate linearly with 5.5 mW/K 500
mW
NOTES:
1. Stresses beyond those listed may cause permanent damage to the device. These are stress ratings only and functional operation of the
device at these or any other conditions beyond those indicated under “recommended operating conditions” is not implied. Exposure to
absolute-maximum-rated conditions for extended periods may affect device reliability.
2. The input and output voltage ratings may be exceeded if the input and output current ratings are observed.
