INTEGRATED CIRCUITS 74LVC04A Hex inverter Product specification Supersedes data of 1997 Mar 28 IC24 Data Handbook 1997 Jun 30
Philips Semiconductors Product specification 74LVC04A Hex inverter FEATURES DESCRIPTION • Wide supply range of 1.2V to 3.6V • Complies with JEDEC standard no. 8-1A • Inputs accept voltages up to 5.5V • CMOS low power consumption • Direct interface with TTL levels • 5-volt tolerant inputs, for interfacing with 5-volt logic The 74LVC04A is a high-performance, low-power, low-voltage, Si-gate CMOS device and superior to most advanced CMOS compatible TTL families. Inputs can be driven from either 3.
Philips Semiconductors Product specification 74LVC04A Hex inverter LOGIC SYMBOL LOGIC DIAGRAM (ONE GATE) 1 1A 1Y 2 3 2A 2Y 4 5 3A 3Y 6 9 4A 4Y 8 5A 5Y 10 11 6A 13 A SV00399 FUNCTION TABLE SV00397 LOGIC SYMBOL (IEEE/IEC) 1 1 2 3 1 4 5 1 6 9 1 8 11 1 10 13 1 12 SV00398 1997 Jun 30 INPUTS OUTPUTS nA nY L H H L NOTES: H = HIGH voltage level L = LOW voltage level 12 6Y Y 3
Philips Semiconductors Product specification 74LVC04A Hex inverter RECOMMENDED OPERATING CONDITIONS LIMITS SYMBOL PARAMETER CONDITIONS UNIT MIN MAX VCC DC supply voltage (for max. speed performance) 2.7 3.6 V VCC DC supply voltage (for low-voltage applications) 1.2 3.6 V 0 5.5 V VI DC Input voltage range VO DC output voltage range Tamb Operating ambient temperature range in free-air tr, tf Input rise and fall times VCC = 1.2 to 2.7V VCC = 2.7 to 3.
Philips Semiconductors Product specification 74LVC04A Hex inverter DC CHARACTERISTICS Over recommended operating conditions voltages are referenced to GND (ground = 0V) LIMITS SYMBOL PARAMETER TEST CONDITIONS Temp = -40°C to +85°C TYP1 MIN VIH HIGH level Input voltage VIL LOW level Input voltage VCC = 1.2V VCC VCC = 2.7 to 3.6V 2.0 V VCC = 1.2V GND V VCC = 2.7 to 3.6V VOH O HIGH level output voltage VOL LOW level output voltage II ICC ∆ICC UNIT MAX 0.8 VCC = 2.
Philips Semiconductors Product specification Hex inverter 74LVC04A SO14: plastic small outline package; 14 leads; body width 3.
Philips Semiconductors Product specification Hex inverter 74LVC04A SSOP14: plastic shrink small outline package; 14 leads; body width 5.
Philips Semiconductors Product specification Hex inverter 74LVC04A TSSOP14: plastic thin shrink small outline package; 14 leads; body width 4.
Philips Semiconductors Product specification Hex inverter 74LVC04A NOTES 1997 Jun 30 9
Philips Semiconductors Product specification Hex inverter 74LVC04A DEFINITIONS Data Sheet Identification Product Status Definition Objective Specification Formative or in Design This data sheet contains the design target or goal specifications for product development. Specifications may change in any manner without notice. Preliminary Specification Preproduction Product This data sheet contains preliminary data, and supplementary data will be published at a later date.
