5.8.3 ADC Clock Register
The ADC clock register (ADCLK) selects the clock frequency for the
ADC.
ADIV2–ADIV0 — ADC Clock Prescaler Bits
ADIV2–ADIV0 form a 3-bit field which selects the divide ratio used by
the ADC to generate the internal ADC clock. Table 5-2 shows the
available clock configurations. The ADC clock should be set to
approximately 1 MHz.
ADICLK — ADC Input Clock Select Bit
ADICLK selects either the bus clock or CGMXCLK as the input clock
source to generate the internal ADC clock. Reset selects CGMXCLK
as the ADC clock source.
Address: $0003E
Bit 7654321Bit 0
Read:
ADIV2 ADIV1 ADIV0 ADICLK
0000
Write:
Reset:00000000
= Unimplemented
Figure 5-4. ADC Clock Register (ADCLK)
Table 5-2. ADC Clock Divide Ratio
ADIV2 ADIV1 ADIV0 ADC Clock Rate
0 0 0 ADC input clock ÷ 1
0 0 1 ADC input clock ÷ 2
0 1 0 ADC input clock ÷ 4
0 1 1 ADC input clock ÷ 8
1 X X ADC input clock ÷ 16
X = don’t care
