22.10.2 TIM Counter Registers
The two read-only TIM counter registers contain the high and low bytes
of the value in the TIM counter. Reading the high byte (TCNTH) latches
the contents of the low byte (TCNTL) into a buffer. Subsequent reads of
TCNTH do not affect the latched TCNTL value until TCNTL is read.
Reset clears the TIM counter registers. Setting the TIM reset bit (TRST)
also clears the TIM counter registers.
NOTE: If you read TCNTH during a break interrupt, be sure to unlatch TCNTL
by reading TCNTL before exiting the break interrupt. Otherwise, TCNTL
retains the value latched during the break.
Address: T1CNTH, $0021 and T1CNTH, $002C
Bit 7654321Bit 0
Read: Bit 15 14 13 12 11 10 9 Bit 8
Write:
Reset:00000000
= Unimplemented
Figure 22-5. TIM Counter Registers High (TCNTH)
Address: T1CNTL, $0022 and T1CNTL, $002D
Bit 7654321Bit 0
Read: Bit 7 654321Bit 0
Write:
Reset:00000000
= Unimplemented
Figure 22-6. TIM Counter Registers Low (TCNTL)
