TSTOP — TIM Stop Bit
This read/write bit stops the TIM counter. Counting resumes when
TSTOP is cleared. Reset sets the TSTOP bit, stopping the TIM
counter until software clears the TSTOP bit.
1 = TIM counter stopped
0 = TIM counter active
NOTE: Do not set the TSTOP bit before entering wait mode if the TIM is required
to exit wait mode.
TRST — TIM Reset Bit
Setting this write-only bit resets the TIM counter and the TIM
prescaler. Setting TRST has no effect on any other registers. Counting
resumes from $0000. TRST is cleared automatically after the TIM
counter is reset and always reads as logic 0. Reset clears the TRST
bit.
1 = Prescaler and TIM counter cleared
0 = No effect
NOTE: Setting the TSTOP and TRST bits simultaneously stops the TIM counter
at a value of $0000.
PS2–PS0 — Prescaler Select Bits
These read/write bits select either the TCLK pin or one of the seven
prescaler outputs as the input to the TIM counter as Table 22-2 shows.
Reset clears the PS[2:0] bits.
Table 22-2. Prescaler Selection
PS2–PS0 TIM Clock Source
000 Internal bus clock ÷1
001 Internal bus clock ÷ 2
010 Internal bus clock ÷ 4
011 Internal bus clock ÷ 8
100 Internal bus clock ÷ 16
101 Internal bus clock ÷ 32
110 Internal bus clock ÷ 64
111 Not available
