7.6.4 PLL Multiplier Select Register Low
The PLL multiplier select register low (PMSL) contains the programming
information for the low byte of the modulo feedback divider.
MUL7–MUL0 — Multiplier Select Bits
These read/write bits control the low byte of the modulo feedback
divider that selects the VCO frequency multiplier, N. (See 7.4.3 PLL
Circuits and 7.4.6 Programming the PLL.) MUL7–MUL0 cannot be
written when the PLLON bit in the PCTL is set. A value of $0000 in the
multiplier select registers configures the modulo feedback divider the
same as a value of $0001. Reset initializes the register to $40 for a
default multiply value of 64.
NOTE: The multiplier select bits have built-in protection such that they cannot
be written when the PLL is on (PLLON = 1).
Address: $0038
Bit 7654321Bit 0
Read:
MUL7 MUL6 MUL5 MUL4 MUL3 MUL2 MUL1 MUL0
Write:
Reset:01000000
Figure 7-7. PLL Multiplier Select Register Low (PMSL)
