PEMD13; PUMD13
NPN/PNP resistor-equipped transistors; R1 = 4.7 k, R2 = 47 k
Fig 19. Reflow soldering footprint PUMD13 (SOT363)
Fig 20. Wave soldering footprint PUMD13 (SOT363)
solder lands
solder resist
occupied area
solder paste
sot363_fr
2.65
2.35
0.4 (2×)
0.6
(2×)
0.5
(4×)
0.5
(4×)
0.6
(4×)
0.6
(4×)
1.5
1.8
Dimensions in mm
sot363_fw
solder lands
solder resist
occupied area
preferred transport
direction during soldering
5.3
1.3 1.3
1.5
0.3
1.5
4.5
2.45
2.5
Dimensions in mm
