NXP Semiconductors
PEMD13; PUMD13
NPN/PNP resistor-equipped transistors; R1 = 4.7 k, R2 = 47 k
11. Soldering
Reflow soldering is the only recommended soldering method.
Fig 18. Reflow soldering footprint PEMD13 (SOT666)
solder lands
placement area
occupied area
solder paste
sot666_fr
2.75
2.45
2.1
1.6
0.4
(6×)
0.55
(2×)
0.25
(2×)
0.6
(2×)
0.65
(2×)
0.3
(2×)
0.325
(4×)
0.45
(4×)
0.5
(4×)
0.375
(4×)
1.72
1.7
1.075
0.538
Dimensions in mm
