- NX series User's Manual POWER SUPPLY

Control keypad
77(86)
7
Applications info submenu (S6.7.6)
At location
S6.7.6
is the Applications submenu containing information about not only the
application currently in use but also all other applications loaded into the frequency converter. The
information available is:
1. Application identification number
2. Application version number
3. Firmware interface number
In the Application information submenu, push the right arrow menu button to enter the Application
pages of which there are as many as there are applications loaded into the frequency converter.
Locate the application you want information about with the Browser buttons and then enter the
Information pages with the right arrow menu button. Use again the Browser buttons to see the
different pages.
Figure 7-23. Applications info submenu
7.3.6.8 Counters menu
In the Counters menu
(S6.8)
is information related to the frequency converter operation times, i.e.
the total numbers of MWh, operation days and operation hours passed so far. Unlike the counters
in the Trip counters submenu, these counters cannot be reset.
Note!
The operation time counter (days and hours) runs always, when the power is on.
Page Counter
C6.8.1. MWh counter
C6.8.2. Operation day counter
C6.8.3. Operation hour counter
Table 7-7. Counter pages
A1
"
A7
I/Oterm I/Oterm
D1
"
D3
I/Oterm
READY READY
READY
D1
"
D3
I/Oterm
NXFIFF01
I/Oterm
Applications Basic
Standard
Application id
Version
