- NX series User's Manual POWER SUPPLY

34(86)
Cabling and connections
6
6.1.2.1 Stripping lengths of motor and mains cables
Figure 6-3. Stripping of cables
Frame
A1 B1
C1 D1 A2 B2 C2 D2
FR4
15 35
10 20 7 50 7 35
FR5
20 40
10 30 20 60 10 40
FR6
20 90
15 60 20 90 15 60
FR7
25 120
25 120 25 120 25 120
FR8
0140
0168—0205
23
28
240
240
23
28
240
240
23
28
240
240
23
28
240
240
Table 6-3. Cables stripping lengths [mm]
nk6141.fh8
MAINS MOTOR
Earth
conductor
Earth
conductor
D1
B1
C1
A1
D2
B2
C2A2
