- NX series User's Manual POWER SUPPLY

Installation
23(86)
5
Figure 5-4. NX dimensions, IP21 with collar, FR7 and FR8
Type
W1 W2 W3 W4 H1 H2 H3 H4 H5 H6 H7 D1 D2
∅
0120—0150 NX_2
0072—0105 NX_5
0085—0122 NX_6
237 175 270 253 652 632 630 188.5 188.5 23 20 257 117 5.5
0140—0205 NX_5 285 –
355 330
832 –
745
258
265
43
57
288 110 9
Table 5-4. Dimensions for different frequency converter types FR7 and FR8, IP21 with collar
W3
W1
W2
H1 H2
H3
D1
D2
H4
H4
H5
H7
W4
H6
fr7kaulusip21.fh8
