Datasheet

Part number in bold face type: ready for despatch within 2 working days
Part number in normal type: ready for despatch within 10 working days
6.114
Main Catalogue
E 03/2009
19" chassis – F
IPA30636
02108050
F
 Load-carrying capacity 35 kg per pair
Delivery comprises (kit)
Order Information
aza43284
F
 The earthing kit ensures VDE compliant earthing of the cases in
accordance with
– DIN EN 50178/VDE 0160
– DIN EN 60950/VDE 0805
– DIN EN 61010-1/VDE 0411 part 1
– DIN EN 61010-1A2/VDE 0411 part 1/A
 VDE inspection carried out
Order Information
Front handles
27
44
Item Qty Description
1 2 Front handle, Al die-cast, powder-coated, RAL 7030 ,
incl. assembly kit
Height Part no.
U
3
20828-127
4
20828-128
6
20828-129
For further information www.schroff.biz/oneclick
oneClick search code = Part no.
Earthing kit
Description Qty/PU Part no.
GND/earthing kit, Cu wire, 1.5 mm
2
,
PVC sheathing, green/yellow, connects
side panels, top and base plate and rear panel
1
21100-814
For further information www.schroff.biz/oneclick
oneClick search code = Part no.
