Replacement Part List

4
Series 1100
AWNING SLAT 6" CATEGORY: Extrusion — SUBCATEGORY: Slat
8 SKU # Model # Description Width
WIDE_SLAT_COLORNAME N/A
Awning Slat
White, Almond, Sandalwood, Brick Red, Burgundy, Brown, Fern
Green, Evergreen, Bedford Blue, Slate Blue, Graystone, Black
6
1
⁄2"
Series 1100
INTERLOCK CLIP (each) CATEGORY: Hardware — SUBCATEGORY: SS Clips
SKU # Model # Description Length
FG47770-R1 N/A
Interlock Clip
Stainless Steel
N/A
Series 1100
2-INCH PAN PHILLIPS SCREWS (each) CATEGORY: Hardware — SUBCATEGORY: Mounting Screw
SKU # Model # Description Length
H0110344 N/A
12x 2-inch Pan Phillips Screw
Zinc
2"
Series 1100
3/8-INCH HEX HEAD SCREWS (each) CATEGORY: Hardware — SUBCATEGORY: Assembly Screw
SKU # Model # Description Length
SIDEWINGSCREWS N/A
#6 x
3
⁄8"
Hex Head Screw
Stainless Steel
3
⁄8"
Series 1100
SIDEWING CONNECTOR (each) CATEGORY: Brackets — SUBCATEGORY: Sidewing
SKU # Model # Description Size
CONNECTOR N/A
Aluminum Sidewing Connector
Mill Finish
2
1
⁄4" tall
by
1
3
⁄4" wide
Series 1100
ADJUSTABLE WALL BRACKET (pair) CATEGORY: Brackets — SUBCATEGORY: Adj. Wall Brkt.
SKU # Model # Description Length
ADJWALLBRKT-AB-MILL N/A Adjustable Wall Bracket for Sidewing 5"
Series 1100
CANOPY EXTRUDED HAT SECTION CATEGORY: Extrusion — SUBCATEGORY: Hat
SKU # Model # Description Size
HAT N/A
Aluminum Canopy Extruded Hat Section
Mill Finish
3
1
⁄8" wide
by
2" tall
