2.0 SPECIFICATIONS
Model PW 124 PW 184 PW 214 PW 254
Maximum Capacity 120g 180g 210g 250g
Readability 0.0001g
Tare Range Full
Repeatability (S.D.) 0.00015g 0.0002g
Linearity (±) 0.0002g
Units of measure grams, milligrams, carats, ounces, pounds, troy ounce, grains,
pennyweights, drams, taels (Hong Kong, Taiwan and Singapore),
mommes, tolas, ticals and newtons
Interface RS-232 bi-directional
Operating
temperature
+ 10°C to 40°C
Power supply Output voltage 15 VDC, 800 mA through
External Power Supply Module- supplied as standard
(Input Voltage 100–240 V, 50/60 Hz)
Calibration Calibration with internal mass. Alternatively the user can chose to
calibrate using an external mass
External Calibration
mass
100 g
Display Backlit LCD with dual digits (24 mm high) and capacity tracker
Draught shield Supplied as standard (factory fitted)
Draught shield
dimensions
202 x 524 x 275 mm
Housing Die cast aluminium housing with glass weighing chamber
Pan size
90 mm ø
Overall dimensions
(wxdxh)
265 x 524 x 275 mm
Net weight 12 kg
Applications Weighing, Check weighing, Percentage weighing, Parts counting,
Animal / dynamic weighing, Net / total and Density determination
