SYMBOLS AND TEXT
The LCD has unique symbols to indicate the following:
0 Zero
Busy
Stable
A bar graph with set point markers
g, mg, ct, oz, lb, ozt, GN, dwt,
dr, tl H, tl T, tl S, MM, T, ti, N,
g/cc, Pcs, %, M, and S
Text is shown for the weighing units and modes
INDICATORS
“ CAL ”
When calibration is occurring or about to occur
“ ºC ”
When a temperature is shown or a temperature driven calibration is to
occur
“ ti ”
For a time driven calibration
“ Net ”
When a net weight is shown
“ PARTS ”
When the balance is in the Parts counting mode
“ PERCENT ”
When the balance is in the Percent weighing mode
“ NT ”
When the balance is in the Net/ Total mode
“ 0% ”, “ 100% ”
When the capacity tracker is showing percent of maximum range used
