INSTALLATION
3.7 AutoPrime™
The AutoPrime™ Liquid End is equipped with a valve that allows for constant removal
of vapors and gasses inherent with effervescent chemicals such as Sodium Hypochlorite
and Hydrogen Peroxide. The valve keeps the pump primed automatically. When install-
ing a pump equipped with an AutoPrime™ Liquid End connect the 1/2" OD Polyethylene
tubing to the top vertical tting, and route this line back to the supply tank. To ensure
priming, this tubing should not be submerged in the solution. The horizontal tting is
the discharge, and the bottom vertical tting is the suction.
Return Fitting
Using 1/2" polyethylene
tubing here and
route to supply tank.
Discharge Fitting
Suction Fitting
