Intended Use
The NorTrac 20 HP Mini-Track Gas Loader is used for digging, carrying materials, grading,
landscaping, ground maintenance, site preparation, and snow removal. With optional attachments
(sold separately), the 20MTL is capable of sweeping, trenching, and more. The steer loader is
designed for operation in small and limited-access spaces. Its standard mini-SSL interface and
hydraulic connections make it compatible with many attachments to perform a wide variety of light and
medium duty tasks.
Technical Specifications
Property
Specification
Overall Width (with bucket)
43.7 in. / 1110 mm.
Overall Length
99.2 in. / 2520 mm.
Overall Height
55.3 in. / 1405 mm.
Maximum Operating Height (with standard bucket)
80.2 in. / 2037 mm.
Operating Weight
3351 lb.
Rated Load Capacity – Bucket (with 198 lb. operator)
750 lb.
Travel Speed
0-4.5 km/h (0-2.8 mph)
Angle of Departure
22º
Engine
14.9 KW
Ground Clearance
4.1 in. / 104 mm.
Hydraulics Flow (auxiliary)
6.5 gal/min
System Relief Pressure (hydraulic)
18 MPa
Hydraulic Oil Tank Capacity
33 liters
Standard Bucket Capacity
0.17m
3
Standard Bucket Dump Height
51.7 in. / 1313 mm.
Height to Hinge Pin
73.5 in. / 1867 mm.
Specifications and design subject to change without notice.
Important Safety Information
⚠WARNING
• Read and understand all instructions. Failure to follow all instructions may result in serious injury
or property damage.
• The warnings, cautions, and instructions in this manual cannot cover all possible conditions or
situations that could occur. Exercise common sense and caution when using this tool. Always be
aware of the environment and ensure that the tool is used in a safe and responsible manner.
• Do not allow persons to operate the machine 20MTL they have read this manual and have
developed a thorough understanding of how it works.
• Do not modify this machine in any way. Unauthorized modification may impair the function and/or
safety and could affect the life of the product and void the warranty. There are specific applications
for which the product was designed.
• Use the right tool for the job. DO NOT attempt to force small equipment to do the work of larger
industrial equipment. There are certain applications for which this equipment was designed. This
product will be safer and do a better job at the capacity for which it was intended. DO NOT use
this equipment for a purpose for which it was not intended.
• Industrial or commercial applications must follow OSHA requirements.
