Alteon OS Command Reference
The Information Menu
9943W7774, May 2007
The following table describes the Tag parameters.
Table 4-25 IP Routing Tag Parameters
Parameter Description
fixed The address belongs to a host or subnet attached to the switch.
static The address is a static route which has been configured on the GbE Switch
Module.
addr The address belongs to one of the switch’s IP interfaces.
rip The address was learned by the Routing Information Protocol (RIP).
ospf The address was learned by Open Shortest Path First (OSPF).
bgp The address was learned via Border Gateway Protocol (BGP)
broadcast Indicates a broadcast address.
martian The address belongs to a filtered group.
multicast Indicates a multicast address.
