Alteon OS Command Reference
The Information Menu
9543W7774, May 2007
/info/l3
Layer 3 Information
The information provided by each menu option is briefly described in Table 4-22, with point-
ers to detailed information.
[Layer 3 Menu]
route - IP Routing Information Menu
arp - ARP Information Menu
bgp - BGP Information Menu
ospf - OSPF Routing Information Menu
rip - RIP Routing Information Menu
ip - Show IP information
igmp - Show IGMP Snooping Multicast Group information
vrrp - Show Virtual Router Redundancy Protocol information
dump - Dump all layer 3 information
Table 4-22 Layer 3 Menu Options (/info/l3)
Command Syntax and Usage
route
Displays the IP Routing Menu. Using the options of this menu, the system displays the following
for each configured or learned route:
Route destination IP address, subnet mask, and gateway address
Type of route
Tag indicating origin of route
Metric for RIP tagged routes, specifying the number of hops to the destination (1-15 hops, or 16
for infinite hops)
The IP interface that the route uses
For details, see page 97.
arp
Displays the Address Resolution Protocol (ARP) Information Menu. For details, see page 100.
bgp
Displays BGP Information Menu. To view menu options, see page 102.
ospf
Displays OSPF routing Information Menu. For details, see page 105.
rip
Displays Routing Information Protocol Menu. For details, see page 110.
