Alteon OS Command Reference
94
The Information Menu 43W7774, May 2007
/info/l2/vlan
VLAN Information
NOTE – The sample screens that appear in this document might differ slightly from the screens
displayed by your system. Screen content varies based on the type of BladeCenter unit that you
are using and the firmware versions and options that are installed.
This information display includes all configured VLANs and all member ports that have an
active link state. Port membership is represented in slot/port format.
VLAN information includes:
VLAN Number
VLAN Name
Status
Port membership of the VLAN
Protocol-based VLAN information
Whether the VLAN is a GVRP dynamic VLAN
Private VLAN configuration
VLAN Name Status Ports
---- -------------------------------- ------ --------------------
1 Default VLAN ena INT1-INT14 EXT1-EXT4
10 VLAN 10 ena INT1
10 *VLAN 10 ena EXT3
30 *VLAN 30 ena EXT4
4095 Mgmt VLAN ena INT1-INT14 MGT
(*) = Dynamically created VLAN
Private-VLAN Type Mapped-To Status Ports
------------ --------- ---------- ---------- -----------------
1000 primary 1001-1014 ena EXT1 EXT2
1001 isolated 1000 ena INT1
1002 community 1000 ena INT2
1003 community 1000 ena INT3
